Flexible Impeller Pump Accessories

Ts Pumps can supply a wide range of accessories with your Flexible Impeller Pump order including Dry-Run Protection, By-Pass Valves, Hygienic Shrouds, Radio Controlled, Trolley Mounted, Automatic Barrel Filling Kit and IRR Centrifugal Sprinkler Kit.

Contact us for pricing
Details
Features & Applications
Tech Info
Performance

Dry Run Protection

Dry Run Protection can be fitted to pump heads from MINOR sizes upwards. It is a temperature sensor that automatically stops the pump once it registers a temperature higher than 50ºC within the pump head. For fluids being pumped higher than this temperature then sensors set at 70 & 90ºC are available on request and need to be specified at the order stage. Once the temperature in the pump head drops below the pre-set value the pump automatically starts back up.

By-Pass Valve

Manual and Spring Loaded By-Passes are available on all pumps can are ideal when the pump is being used with a discharge nozzle or there is the potential for Dead Head Operation.

Manual By-Passes: MINI, MAJOR, MAX Pump Types Spring Loaded By-Passes: MIDEX & MINOR Pup Types.

Hygienic Shrouds

  1. Hygienic Shrouds for use in food environments & Wash Down Areas
  2. Mounted to SS 316 Baseplates or Trolleys
  3. Trolleys are fitted with white Food Grade Wheels
  4. Trolley mounted units come with the standard CE Compliant Control Panel
Flexible Impeller Pump Hygienic Shroud

IRR Centrifugal Sprinkler Kit

The IRR Centrifugal Sprinkler Kit rotates using the pressure of the feed pump and is available in 2 set sizes:

IRR 50: Suitable for an Impeller Pump with a capacity from 100 – 225 hl/hr

IRR 65: Suitable for pumps with a capacity from 225 – 500 hl/hr It provides a universal drizzling effect from the cap granting excellent colour leaching, Standard fastenings are for 400 mm manways. however, larger dimensions are available on request.

Visit the product page for information on the Flexible Impeller Automatic Barrel Filling Kit.



If you have further questions, our Pump Specialists will have the answer.

Please don't hesitate to get in touch:

01928 333 400
[email protected]

IRR Centrifugal Sprinkler Kit

The IRR Centrifugal Sprinkler Kit is available in 2 sizes, IRR 50 or IRR 65.

The kit uses the pressure from the feed pump to rotate and creates a drizzling effect which provides quality colour leaching.



IRR Centrifugal Sprinkler Kit Size Suitable pump capacity
IRR 50 100 – 225 hl/hr
IRR 65 225 – 500 hl/hr
